| Varenummer | CLAA220WA01 |
| Mærke | CPT |
| Størrelse | 21.6 |
| Ansøgning | DMPC |
| Løsning | 1680×1050 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | CPT |
| panel model | CLAA220WA01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 21.6 inch |
| løsning | 1680(RGB)×1050 , WSXGA+ |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 464.94×290.587 mm |
| omrids | 493.7×320.1 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC), CIE193172% |
| responstid | 5 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/75/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 4 pcsCCFLWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | DMPC |
| CLAA215FA01 | CPT | 21.5 | 1920×1080 |
| CLAA215FA04 | CPT | 21.5 | 1920×1080 |
| CLAA215FA04 V4 | CPT | 21.5 | 1920×1080 |
| CLAA220WA01 | CPT | 21.6 | 1680×1050 |
| CLAA260WU09 | CPT | 25.5 | 1920×1200 |
| CLAA260WU09M | CPT | 25.5 | 1920×1200 |
| M216H1-L01 | Innolux | 21.6 | 1920×1080 |
| T216XW01 V0 | AUO | 21.6 | 1366×768 |
| T216XW01 V3 | AUO | 21.6 | 1366×768 |
| V216B1-L01 | Innolux | 21.6 | 1366×768 |
| LM238WF4-SSA1 | LG Display | 23.8 | 1920×1080 |
| LM240WU7-SLA3 | LG Display | 24.0 | 1920×1200 |
| LM250WF3-TLA1 | LG Display | 25.0 | 1920×1080 |
| LM270WQ1-SDE3 | LG Display | 27.0 | 2560×1440 |
| LTM170EU-A01 | Samsung | 17.0 | 1280×1024 |
| LTM190EX-L21 | Samsung | 19.0 | 1280×1024 |
| M190EN04 V1 | AUO | 19.0 | 1280×1024 |
| M230HGE-L20 | Innolux | 23.0 | 1920×1080 |
| T215HVN01.1 | AUO | 21.5 | 1920×1080 |
| TMS150XG1-10TB Rev.E | Tianma | 15.0 | 1024×768 |
