| Varenummer | LTM170EU-A01 |
| Mærke | Samsung |
| Størrelse | 17.0 |
| Ansøgning | DMPC |
| Løsning | 1280×1024 |
| Sammensætning | LCM |
| Lysstyrke | 270 |
| CR | 400:1 |
| Farver | 16.2M |
| Baggrundsbelysning | CCFL |
| Interface | Analog |
| panel mærke | SAMSUNG |
| panel model | LTM170EU-A01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 17.0 inch |
| løsning | 1280(RGB)×1024 , SXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 337.92×270.336 mm |
| omrids | 358.5×296.5×25.4 mm |
| overflade | Antiglare (Haze 25%), Hard coating (3H) |
| lysstyrke | 270 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.) |
| vise farver | 16.2M (6-bit + FRC), CIE193165% |
| responstid | 5/20 (Typ.)(Tr/Td) |
| synsvinkel | 60/60/50/50 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 4 pcsCCFLEmbedded (Inverter) |
| signal interface | Analog RGB, 27 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | DMPC |
