| Varenummer | EV121WXM-N12 |
| Mærke | BOE |
| Størrelse | 12.1 |
| Ansøgning | Medical Imaging |
| Løsning | 1280×800 |
| Sammensætning | a-Si TFT-LCD, LCM |
| Lysstyrke | |
| CR | 1200:1 |
| Farver | 262K/16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| mærke | BOE |
| model | EV121WXM-N12 |
| diagonal størrelse | 12.1 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 1280(RGB)×800 [WXGA] 124PPI |
| konfiguration | RGB Vertical Stripe |
| aktivt område | 261.12(H)×163.2(V) mm |
| omrids dim. | 277.7(H)×180.6(V) ×9.2(D) mm |
| bezel område | 264.12(H)×166.2(V) mm |
| behandling | Antiglare (Haze 25%) |
| luminans | 500 cd/m² (Typ.) |
| kontrastforhold | 1200:1 (Typ.) (TM) |
| visningsretning | Symmetry |
| responstid | 30 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10) |
| driftstilstand | ADS, Normally Black, Transmissive |
| støtte farve | 262K/16.7M 100% sRGB |
| lyskilde | WLED [12S4P] , 50K hours , With LED Driver |
| vægt | TBD |
| designet til | Medical Imaging |
| billedhastighed | 60Hz |
| berøringspanel | Without |
| interface type | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| Strømforsyning | 3.3V (Typ.) |
| miljø | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
