| Varenummer | G070VTN01.0 |
| Mærke | AUO |
| Størrelse | 7.0 |
| Ansøgning | IA |
| Løsning | 800×480 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 500:1 |
| Farver | 262K/16.2M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | AUO |
| panel model | G070VTN01.0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 7.0 inch |
| løsning | 800×480(RGB) , WVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 152.4×91.44 mm |
| omrids | 170×111×8.3 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 262K/16.2M (6-bit / 6-bit + FRC), CIE193150% |
| responstid | 12/18 (Typ.)(Tr/Td) |
| synsvinkel | 65/65/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 3S7PWLEDWithout Driver |
| signal interface | LVDS (1 ch, 6/8-bit), 20 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | IA |
| 70WVW3T | SII | 7.0 | 800×480 |
| G070VTN01.0 | AUO | 7.0 | 800×480 |
| G070VTT01.0 | AUO | 7.0 | 800×480 |
| G070VVN01.0 | AUO | 7.0 | 800×480 |
| G070VVN01.1 | AUO | 7.0 | 800×480 |
| G070VW01 V0 | AUO | 7.0 | 800×480 |
| G070VW01 V1 | AUO | 7.0 | 800×480 |
| LMS700KF21 | Samsung | 7.0 | 800×480 |
| TX18D11VM1CAA | KOE | 7.0 | 800×480 |
| VVX07F015M00 | Panasonic | 7.0 | 1200×1920 |
| AA057VG02 | Mitsubishi | 5.7 | 640×480 |
| AM-1024600L3TMQW-T05H | AMPIRE | 10.1 | 1024×600 |
| G104X1-L04 | Innolux | 10.4 | 1024×768 |
| LJ640U34 | SHARP | 8.9 | 640×400 |
| LMG7410PLFC | KOE | 5.1 | 240×128 |
| PM062HT1 | E Ink | 6.2 | 640×240 |
| TFD50W72MS | TOSHIBA | 5.0 | |
| TX23D12VM0CAA | KOE | 9.0 | 800×480 |
| UG-2864KLBLG01 | WiseChip | 1.3 | 128×64 |
| UG-5664ASGEF01 | WiseChip | 3.1 | 256×64 |
