| Varenummer | PM062HT1 |
| Mærke | E Ink |
| Størrelse | 6.2 |
| Ansøgning | IA |
| Løsning | 640×240 |
| Sammensætning | LCM |
| Lysstyrke | 280 |
| CR | 600:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | TTL |
| panel mærke | PVI |
| panel model | PM062HT1 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 6.2 inch |
| løsning | 640(RGB)×240 , HVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 148.8×53.76 mm |
| omrids | 173×70×8.9 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 280 cd/m² (Typ.) |
| kontrastforhold | 600:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 15/25 (Typ.)(Tr/Td) |
| synsvinkel | 75/75/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit), 40 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | IA |
