| Varenummer | G121I1-L01 |
| Mærke | Innolux |
| Størrelse | 12.1 |
| Ansøgning | IA |
| Løsning | 1280×800 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 1000:1 |
| Farver | 262K/16.2M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | CMO |
| panel model | G121I1-L01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 12.1 inch |
| løsning | 1280(RGB)×800 , WXGA |
| visningstilstand | MVA, Normally Black, Transmissive |
| aktivt område | 261.12×163.2 mm |
| omrids | 278×184×10.5 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 262K/16.2M (6-bit / 6-bit + FRC), CIE193145% |
| responstid | 15/10 (Typ.)(Tr/Tf) |
| synsvinkel | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 9S3PWLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 6/8-bit), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | IA |
| B121EW03 V6 | AUO | 12.1 | 1280×800 |
| CLAA121UA01CW | CPT | 12.1 | 1600×900 |
| G121I1-L01 | Innolux | 12.1 | 1280×800 |
| HT12X21-240 | HYDIS | 12.1 | 1024×768 |
| LQ121S1LG84 | SHARP | 12.1 | 800×600 |
| LT121DEE3P00 | TOSHIBA | 12.1 | 1024×768 |
| LTM12C505D | TOSHIBA | 12.1 | 1024×768 |
| LTN121XJ-L03 | Samsung | 12.1 | 1024×768 |
| NL8060BC31-13A | NLT | 12.1 | 800×600 |
| NL8060BC31-28D | NLT | 12.1 | 800×600 |
| AA084VB01 | Mitsubishi | 8.4 | 640×480 |
| AA084VC03 | Mitsubishi | 8.4 | 640×480 |
| AA150XT01 | Mitsubishi | 15.0 | 1024×768 |
| G150XGE-L04 | Innolux | 15.0 | 1024×768 |
| LB121S03-TL01 | LG Display | 12.1 | 800×600 |
| LM104VC1T51H | SHARP | 10.4 | 640×480 |
| LQ121S1DG61 | SHARP | 12.1 | 800×600 |
| LTA121C32HF | TOSHIBA | 12.1 | 800×600 |
| SX21V001-Z4A | KOE | 8.2 | 640×480 |
| TM057KDHG10 | Tianma | 5.7 | 320×240 |
