| Varenummer | LQ121S1DG61 |
| Mærke | SHARP |
| Størrelse | 12.1 |
| Ansøgning | IA |
| Løsning | 800×600 |
| Sammensætning | LCM |
| Lysstyrke | 450 |
| CR | 600:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | TTL |
| panel mærke | SHARP |
| panel model | LQ121S1DG61 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 12.1 inch |
| løsning | 800(RGB)×600 , SVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 246×184.5 mm |
| omrids | 276×209×11 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 450 cd/m² (Typ.) |
| kontrastforhold | 600:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 10/25 (Typ.)(Tr/Td) |
| synsvinkel | 70/70/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 2 pcsCCFLWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit), 41 pins |
| indgangsspænding | 3.3/5.0V (Typ.)(VCC) |
| Ansøgning | IA |
| LQ121S1DG21 | SHARP | 12.1 | 800×600 |
| LQ121S1DG21A | SHARP | 12.1 | 800×600 |
| LQ121S1DG31 | SHARP | 12.1 | 800×600 |
| LQ121S1DG41 | SHARP | 12.1 | 800×600 |
| LQ121S1DG61 | SHARP | 12.1 | 800×600 |
| LQ121S1LG44 | SHARP | 12.1 | 800×600 |
| LQ121S1LG45 | SHARP | 12.1 | 800×600 |
| LQ121S1LG55 | SHARP | 12.1 | 800×600 |
| LQ121S1LG79 | SHARP | 12.1 | 800×600 |
| LQ121X3LH01 | SHARP | 12.1 | 1024×768 |
| AA150XT11 | Mitsubishi | 15.0 | 1024×768 |
| BRS-320H02 | 32.0 | 1920×1080 | |
| DLC1040ABG-T | Other | 10.4 | 800×600 |
| DMF-50840NB-FW | Kyocera | 5.7 | 320×240 |
| G215HVN01.0 S03 | AUO | 21.5 | 1920×1080 |
| KCS057QV1AJ-G32 | Kyocera | 5.7 | 320×240 |
| LM-CK53-22NFR | SANYO | 9.4 | 640×480 |
| NL12876AC18-03 | NLT | 10.6 | 1280×768 |
| SX21V001-Z4A | KOE | 8.2 | 640×480 |
| UG-2864HMBEG01 | WiseChip | 0.96 | 128×64 |
