| Varenummer | HT140WXB-100 |
| Mærke | BOE |
| Størrelse | 14.0 |
| Ansøgning | NBPC |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 220 |
| CR | 500:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | BOE |
| panel model | HT140WXB-100 30 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 14.0 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 309.399×173.952 mm |
| omrids | 323.5×192×5.2 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| overflade | Glare (Haze 0%), Hard coating (3H) |
| lysstyrke | 220 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193160% |
| responstid | 8 (Typ.)(Tr+Td) |
| synsvinkel | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 8S6PWLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 6-bit), 40 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| BT140GW01 V.0 | Innolux | 14.0 | 1366×768 |
| HT140WXB-100 | BOE | 14.0 | 1366×768 |
| HT140WXB-501 | BOE | 14.0 | 1366×768 |
| HT140WXB-601 | BOE | 14.0 | 1366×768 |
| LP140WH1-TLA1 | LG Display | 14.0 | 1366×768 |
| LP140WH1-TLB3 | LG Display | 14.0 | 1366×768 |
| LP140WH1-TLD2 | LG Display | 14.0 | 1366×768 |
| LTN140AT16-401 | Samsung | 14.0 | 1366×768 |
| N140BGE-L33 | Innolux | 14.0 | 1366×768 |
| N140FGE-L32 | Innolux | 14.0 | 1600×900 |
| B141XN03 V0 | AUO | 14.1 | 1024×768 |
| B156XTN04.5 | AUO | 15.6 | 1366×768 |
| LP121X1-A2M1 | LG Display | 12.1 | 1024×768 |
| LP154W02-TL06 | LG Display | 15.4 | 1680×1050 |
| LP156WF1-TLF3 | LG Display | 15.6 | 1920×1080 |
| LQ133K1LD4B | SHARP | 13.3 | 1280×800 |
| LQ13X32 | SHARP | 13.3 | 1024×768 |
| LTN141AT12-J01 | Samsung | 14.1 | 1280×800 |
| LTN170CT03-004 | Samsung | 17.0 | 1920×1200 |
| N140BGE-E33 | Innolux | 14.0 | 1366×768 |
