| Varenummer | HT14P12-101 |
| Mærke | HYDIS |
| Størrelse | 14.1 |
| Ansøgning | NBPC |
| Løsning | 1400×1050 |
| Sammensætning | LCM |
| Lysstyrke | |
| CR | |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | HYDIS |
| panel model | HT14P12-101 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 14.1 inch |
| løsning | 1400(RGB)×1050 , SXGA+ |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 285.6×214.2 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| overflade | |
| lysstyrke | |
| kontrastforhold | |
| vise farver | 262K (6-bit) |
| responstid | |
| synsvinkel | |
| frekvens | 60Hz |
| lampe type | CCFL |
| signal interface | LVDS |
| Ansøgning | NBPC |
