| Varenummer | HV121P01-100 |
| Mærke | HYDIS |
| Størrelse | 12.1 |
| Ansøgning | PAD |
| Løsning | 1400×1050 |
| Sammensætning | LCM |
| Lysstyrke | 190 |
| CR | 500:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | BOE HYDIS |
| panel model | HV121P01-100 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 12.1 inch |
| løsning | 1400(RGB)×1050 , SXGA+ |
| visningstilstand | AFFS, Normally Black, Transmissive |
| aktivt område | 245.7×184.275 mm |
| omrids | 270×199×7 mm |
| overflade | Antiglare (Haze 40%), Hard coating (2H) |
| lysstyrke | 190 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193143% |
| responstid | 20/20 (Typ.)(Tr/Td) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 6-bit), 20 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | PAD |
