| Varenummer | VVX09F035M20 |
| Mærke | Panasonic |
| Størrelse | 8.9 |
| Ansøgning | PAD |
| Løsning | 1920×1200 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 800:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| panel mærke | Panasonic |
| panel model | VVX09F035M20 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 8.9 inch |
| løsning | 1920(RGB)×1200 , WUXGA |
| visningstilstand | IPS-Pro, Normally Black, Transmissive |
| aktivt område | 191.52×119.7 mm |
| omrids | 203.5×135.9×4.8 mm |
| overflade | Hard coating |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 16.7M (6-bit + Dithering), CIE193150% |
| responstid | 30 (Max.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Min.)(CR≥80)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 7S5PWLEDWithout Driver |
| signal interface | eDP (2 Lanes), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | PAD |
| CLAA089NA0FCW | CPT | 8.9 | 1024×600 |
| HSD089IFW3-A00 | HannStar | 8.9 | 1024×600 |
| HV089WU1-1E0 | HYDIS | 8.9 | 1920×1200 |
| LD089WU1-SM01 | LG Display | 8.9 | 1920×1200 |
| LP089WS2-TLB1 | LG Display | 8.9 | 1024×600 |
| LT089AC29000 | TOSHIBA | 8.9 | 1280×768 |
| LTD089EXWS | TOSHIBA | 8.9 | 1280×768 |
| LTM09C362 | TOSHIBA | 8.9 | 1024×600 |
| TFT08925601600 | SEBO | 8.9 | 2560×1600 |
| VVX09F035M20 | Panasonic | 8.9 | 1920×1200 |
| B101EAN01.1 | AUO | 10.1 | 1280×800 |
| B101EAN01.2 | AUO | 10.1 | 1280×800 |
| BP101WX1-206 | BOE | 10.1 | 1280×800 |
| CLAA070WP03XG | CPT | 7.0 | 800×1280 |
| CLAA101WH12 LE | CPT | 10.1 | 1280×800 |
| HV101HD1-1E0 | HYDIS | 10.1 | 1366×768 |
| LP097X02-SLG4 | LG Display | 9.7 | 1024×768 |
| LP097X02-SLN1 | LG Display | 9.7 | 1024×768 |
| LP125WH2-SLB3 | LG Display | 12.5 | 1366×768 |
| LTN097QL01-A01 | Samsung | 9.7 | 2048×1536 |
