| Varenummer | HV150UX2-100 |
| Mærke | HYDIS |
| Størrelse | 15.0 |
| Ansøgning | NBPC |
| Løsning | 1600×1200 |
| Sammensætning | LCM |
| Lysstyrke | 200 |
| CR | 600:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | HYDIS |
| panel model | HV150UX2-100 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 15.0 inch |
| løsning | 1600(RGB)×1200 , UXGA |
| visningstilstand | FFS, Normally Black, Transmissive |
| aktivt område | 304.8×228.6 mm |
| omrids | 317.3×243×7 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| overflade | Antiglare (Haze 40%), Hard coating (2H) |
| lysstyrke | 200 cd/m² (Typ.) |
| kontrastforhold | 600:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193145% |
| responstid | 45 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (2 ch, 6-bit), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| CLAA150XP01 | CPT | 15.0 | 1024×768 |
| HV150UX1-100 | HYDIS | 15.0 | 1600×1200 |
| HV150UX1-101 | HYDIS | 15.0 | 1600×1200 |
| HV150UX2-100 | HYDIS | 15.0 | 1600×1200 |
| LQ150X1LW72 | SHARP | 15.0 | 1024×768 |
| LTN150PF-L04 | Samsung | 15.0 | 1400×1050 |
| LTN150U2-L02 | Samsung | 15.0 | 1600×1200 |
| QD15XL06 Rev.01 | QDI | 15.0 | 1024×768 |
| TM150TDS50 | Tianma | 15.0 | 1024×768 |
| TMS150XG1-10TB | Tianma | 15.0 | 1024×768 |
| B141XG03 V2 | AUO | 14.1 | 1024×768 |
| B156XTN04.5 | AUO | 15.6 | 1366×768 |
| CLAA156WA07A | CPT | 15.6 | 1366×768 |
| LP154WX7-TLP1 | LG Display | 15.4 | 1280×800 |
| LP171WX2-TLA2 | LG Display | 17.1 | 1440×900 |
| LTD104EA5R | TOSHIBA | 10.4 | 1024×768 |
| LTD121EDDZ | TOSHIBA | 12.1 | 1024×768 |
| LTN133YL01-F01 | Samsung | 13.3 | 3200×1800 |
| LTN140AT21-801 | Samsung | 14.0 | 1366×768 |
| LTN156AT35-H01 | Samsung | 15.6 | 1366×768 |
