| Varenummer | HV550QUB-B10 |
| Mærke | BOE |
| Størrelse | 55 |
| Ansøgning | LCTV |
| Løsning | 3840×2160 |
| Sammensætning | CELL |
| Lysstyrke | 0 |
| CR | 1200:1 |
| Farver | 1.07B |
| Baggrundsbelysning | No B/L |
| Interface | V-by-One |
| panel mærke | BOE |
| panel model | HV550QUB-B10 |
| paneltype | a-Si TFT-LCD , CELL |
| panelstørrelse | 55 inch |
| løsning | 3840(RGB)×2160 , UHD |
| visningstilstand | ADS, Normally Black, Transmissive |
| aktivt område | 1209.6×680.4 mm |
| omrids | 1219.6×686.8 mm |
| overflade | Antiglare (Haze 1%) |
| transmissivitet | 4.5% (Typ.)(with Polarizer) |
| kontrastforhold | 1200:1 (Typ.) |
| vise farver | 1.07B (8-bit + Hi-FRC) |
| responstid | 6 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| signal interface | V-by-One 8 lane, 51 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | LCTV |
| HV550QUB-B10 | BOE | 55 | 3840×2160 |
| HV550WUP-200 | BOE | 55 | 1920×1080 |
| LC550DUN-PGP2 | LG Display | 55 | 1920×1080 |
| LC550EQD-FGF2 | LG Display | 55 | 3840×2160 |
| LC550EUD-SCA1 | LG Display | 55 | 1920×1080 |
| LC550WUD-SCA1 | LG Display | 55 | 1920×1080 |
| LD550DUN-TGB1 | LG Display | 55 | 1920×1080 |
| LTI550HJ05 | Samsung | 55 | 1920×1080 |
| MT5461D01-3 | CSOT | 55 | 3840×2160 |
| V546H1-LH2 | Innolux | 55 | 1920×1080 |
| AX080A080G | KOE | 31.5 | 1366×768 |
| LC420DUN-SEU3 | LG Display | 42 | 1920×1080 |
| LC420WU1-SLB1 | LG Display | 42 | 1920×1080 |
| LC420WUE-SAB1 | LG Display | 42 | 1920×1080 |
| LC470EUF-PEF1 | LG Display | 47 | 1920×1080 |
| LM315TA6A | PANDA | 31.5 | 1366×768 |
| T260XW01 V5 | AUO | 26.0 | 1280×768 |
| T320HVN02.0 CELL | AUO | 31.5 | 1920×1080 |
| T420XW01 V5 | AUO | 42 | 1366×768 |
| V645HQ1-LS1 | Innolux | 65 | 1920×1080 |
