| Varenummer | JJ070IA-18L |
| Mærke | Innolux |
| Størrelse | 7.0 |
| Ansøgning | Automotive Display |
| Løsning | 800×480 |
| Sammensætning | LCM , a-Si TFT-LCD |
| Lysstyrke | |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | 7S2P |
| Interface | LVDS |
| fabrikant | Innolux |
| skærmstørrelse | 7.0 inch |
| pixel antal | 800(RGB)×480 (WVGA) 133PPI |
| aktivt område (mm) | 152.4 × 91.44 (H×V) |
| rammeareal (mm) | 155.4 × 94.44 (H×V) |
| luminans | 750 cd/m² (Typ.) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10) |
| god udsigt kl | Symmetry |
| farvedybde | 16.7M 70% NTSC |
| masse | 195±9g |
| opdateringshastighed | 60Hz |
| signaltype | LVDS (1 ch, 8-bit) , 50 pins FPC |
| spændingsforsyning | 3.3/13.3/26/-7V (Typ.)(VDD/VDDA/VGH/VGL) |
| max. vurderinger | Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.0G (19.6 m/s²) |
| modelnavn | JJ070IA-18L |
| skærmtype | LCM , a-Si TFT-LCD |
| arrangement | RGB Vertical Stripe |
| omrids (mm) | 162.8 × 104.84 (H×V×D) |
| behandling | Antiglare |
| kontrastforhold | 1000 : 1 (Typ.) (TM) |
| respons | 15/10 (Typ.)(Tr/Td) ms |
| arbejdstilstand | IPS, Normally Black, Transmissive |
| baggrundsbelysning | 7S2P WLED , 20K hours , No Driver |
| anvendes til | Automotive Display |
| berøringsskærm | Without |
