| Varenummer | KB430DF15-L01 |
| Mærke | BEST |
| Størrelse | 43 |
| Ansøgning | Digital Signage Outd |
| Løsning | 1920×1080 |
| Sammensætning | LCM, a-Si TFT-LCD |
| Lysstyrke | |
| CR | 1200:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| fabrikant | BEST |
| modelnavn | KB430DF15-L01 |
| skærmstørrelse | 43 inch |
| skærmtype | LCM, a-Si TFT-LCD |
| pixel antal | 1920(RGB)×1080 (FHD) 51PPI |
| arrangement | RGB Vertical Stripe |
| aktivt område (mm) | 941.184 × 529.416 (H×V) |
| omrids (mm) | 976.5 × 569.5 × 74 (H×V×D) |
| rammeareal (mm) | - |
| behandling | Antiglare (Haze 1%), Hard coating (2H) |
| luminans | 1500 cd/m² (Typ.) |
| kontrastforhold | 1200 : 1 (Typ.) (TM) |
| synsvinkel | 89/89/89/89 (Min.)(CR≥10) |
| respons | 8 (Typ.)(G to G)(B/W) ms |
| god udsigt kl | Symmetry |
| arbejdstilstand | Normally Black, Transmissive |
| farvedybde | 16.7M 68% NTSC |
| baggrundsbelysning | WLED , 30K hours , With LED Driver |
| masse | 14.6Kgs (Typ.) |
| anvendes til | Digital Signage Outdoor High Brightness |
| opdateringshastighed | 60Hz |
| berøringsskærm | Without |
| signaltype | LVDS (2 ch, 8-bit) , Connector 51 pins |
| spændingsforsyning | 12.0V (Typ.) |
| max. vurderinger | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
