| Varenummer | KCB6448BSTT-X1 |
| Mærke | Kyocera |
| Størrelse | 10.4 |
| Ansøgning | IA |
| Løsning | 640×480 |
| Sammensætning | LCM |
| Lysstyrke | |
| CR | 20:1 |
| Farver | Color |
| Baggrundsbelysning | CCFL |
| Interface | Parallel Data |
| panel mærke | Kyocera |
| panel model | KCB6448BSTT-X1 |
| paneltype | CSTN-LCD , LCM |
| panelstørrelse | 10.4 inch |
| løsning | 640(RGB)×480 , VGA |
| visningstilstand | STN, Normally Black, Transmissive |
| aktivt område | 211.2×158.4 mm |
| overflade | |
| lysstyrke | |
| kontrastforhold | 20:1 (Typ.) |
| vise farver | Color , CIE193140% |
| responstid | 160/80 (Typ.)(Tr/Td) |
| synsvinkel | |
| frekvens | 75Hz |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | Parallel Data (2ch, 8-bit) |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | IA |
| B104SN01 V0 | AUO | 10.4 | 800×600 |
| G104V1-T01 | Innolux | 10.4 | 640×480 |
| KCB6448BSTT-X1 | Kyocera | 10.4 | 640×480 |
| KCB6448BSTT-X11 | Kyocera | 10.4 | 640×480 |
| KCB6448BSTT-X4 | Kyocera | 10.4 | 640×480 |
| KCB6448BSTT-X5 | Kyocera | 10.4 | 640×480 |
| LM64P89L | SHARP | 10.4 | 640×480 |
| LQ104V1DG83 | SHARP | 10.4 | 640×480 |
| LQ10D368 | SHARP | 10.4 | 640×480 |
| LTM10C209H | TOSHIBA | 10.4 | 640×480 |
| AA084VB02 | Mitsubishi | 8.4 | 640×480 |
| DLC0570BDG-3 | Other | 5.7 | 640×480 |
| G185HAN01.0 | AUO | 18.5 | 1920×1080 |
| HM150X01-101 | BOE | 15.0 | 1024×768 |
| LM641836R | SHARP | 9.4 | 640×480 |
| LQ235D1LW03 | SHARP | 23.6 | 1920×1080 |
| LTM09C016K | TOSHIBA | 9.4 | 640×480 |
| PD057VU7 | E Ink | 5.7 | 320×240 |
| SP14N003 | KOE | 5.1 | 240×128 |
| UG-5664ASGGF01 | WiseChip | 5.5 | 256×64 |
