| Varenummer | KCB6448BSTT-X5 |
| Mærke | Kyocera |
| Størrelse | 10.4 |
| Ansøgning | IA |
| Løsning | 640×480 |
| Sammensætning | LCM |
| Lysstyrke | 130 |
| CR | 20:1 |
| Farver | Color |
| Baggrundsbelysning | CCFL |
| Interface | Parallel Data |
| panel mærke | Kyocera |
| panel model | KCB6448BSTT-X5 |
| paneltype | CSTN-LCD , LCM |
| panelstørrelse | 10.4 inch |
| løsning | 640(RGB)×480 , VGA |
| visningstilstand | STN, Normally Black, Transmissive |
| aktivt område | 211.2×158.4 mm |
| omrids | 264×183 mm |
| overflade | Antiglare |
| lysstyrke | 130 cd/m² (Typ.) |
| kontrastforhold | 20:1 (Typ.) |
| vise farver | Color , CIE193140% |
| responstid | 160/80 (Typ.)(Tr/Td) |
| synsvinkel | 45/45/35/20 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 75Hz |
| lampe type | 2 pcsCCFLWithout Driver |
| signal interface | Parallel Data (2ch, 8-bit), 29 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | IA |
