| Varenummer | KCG057QV1DL-G770 |
| Mærke | Kyocera |
| Størrelse | 5.7 |
| Ansøgning | Industrial |
| Løsning | 320×240 |
| Sammensætning | CSTN-LCD, LCM |
| Lysstyrke | |
| CR | 55:1 |
| Farver | Color |
| Baggrundsbelysning | CCFL |
| Interface | Parallel |
| mærke | Kyocera |
| model | KCG057QV1DL-G770 |
| diagonal størrelse | 5.7 inch |
| type | CSTN-LCD, LCM |
| pixel format | 320(RGB)×240 [QVGA] 70PPI |
| konfiguration | RGB Vertical Stripe |
| aktivt område | 115.2(H)×86.4(V) mm |
| omrids dim. | 144(H)×104.8(V) ×15.3(D) mm |
| bezel område | 119.4(H)×90.6(V) mm |
| behandling | Hard coating (2H) |
| luminans | - |
| kontrastforhold | 55:1 (Typ.) (TM) |
| visningsretning | - |
| responstid | 180/170 (Typ.)(Tr/Td) |
| synsvinkel | 50/50/20/35 (Typ.)(CR≥2) |
| driftstilstand | STN, Normally Black, Transmissive |
| støtte farve | Color |
| lyskilde | CCFL [1 pcs] |
| vægt | 220g (Typ.) |
| designet til | Industrial |
| billedhastighed | 75Hz |
| berøringspanel | 4-wire Resistive Touch |
| interface type | Parallel Data (1ch, 8-bit) Connector |
| Strømforsyning | 3.3/5.0V (Typ.)(VDD) |
| miljø | Operating Temperature: 0 ~ 60 °C ; Storage Temperature: -20 ~ 60 °C |
