| Varenummer | LA123WF1-SL01 |
| Mærke | LG Display |
| Størrelse | 12.3 |
| Ansøgning | CNS |
| Løsning | 1920×720 |
| Sammensætning | LCM |
| Lysstyrke | 720 |
| CR | 900:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | LG Display |
| panel model | LA123WF1-SL01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 12.3 inch |
| løsning | 1920(RGB)×720 |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 292.032×109.512 mm |
| omrids | 310×128×20.6 mm |
| overflade | Hard coating |
| lysstyrke | 720 cd/m² (Typ.) |
| kontrastforhold | 900:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193186% |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 11S3PWLEDWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 110 pins |
| indgangsspænding | 3.3/13.0V (Typ.)(VCC/VDD) |
| Ansøgning | CNS |
| 70WVW4A | SII | 7.0 | 800×480 |
| C070VVN03.1 | AUO | 7.0 | 800×480 |
| C080VW02 V0 | AUO | 8.0 | 800×480 |
| C123HAN01.1 | AUO | 12.3 | 1920×720 |
| CLAA070JA1BCW | CPT | 7.0 | 480×234 |
| LA061WQ1-TD05 | LG Display | 6.1 | 480×272 |
| LB070WQ6-TD01 | LG Display | 7.0 | 400×234 |
| LQ065T9DR51U | SHARP | 6.5 | 400×240 |
| PW065XS1 | E Ink | 6.5 | 400×234 |
| PW070XUA | E Ink | 7.0 | 480×234 |
