| Varenummer | LB070WQ6-TD01 |
| Mærke | LG Display |
| Størrelse | 7.0 |
| Ansøgning | CNS |
| Løsning | 400×234 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 500:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | TTL |
| panel mærke | LG.Philips LCD |
| panel model | LB070WQ6-TD01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 7.0 inch |
| løsning | 400(RGB)×234 |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 156.25×82.37 mm |
| omrids | 167.5×93.2 mm |
| overflade | |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | |
| synsvinkel | 65/65/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | CCFL |
| signal interface | TTL (1 ch, 6-bit) |
| Ansøgning | CNS |
| LB070WQ4-TM01 | LG Display | 7.0 | 480×234 |
| LB070WQ5-TD01 | LG Display | 7.0 | 480×240 |
| LB070WQ6-TD01 | LG Display | 7.0 | 400×234 |
| LB070WQ7-TD02 | LG Display | 7.0 | 480×234 |
| LB070WV1-TD04 | LG Display | 7.0 | 800×480 |
| LB070WV3-SD01 | LG Display | 7.0 | 800×480 |
| LB070WV3-SD02 | LG Display | 7.0 | 800×480 |
| LB070WV4-TJ01 | LG Display | 7.0 | 800×480 |
| LB070WV6-TD08 | LG Display | 7.0 | 800×480 |
| LB070WV7-TD02 | LG Display | 7.0 | 800×480 |
| A070FW01 | AUO | 7.0 | 480×234 |
| AT080TN42 V.1 | Innolux | 8.0 | 800×600 |
| CLAA069LA0FCW | CPT | 7.0 | 800×480 |
| CLAA069LB06 CW | CPT | 7.0 | 800×480 |
| G070Y2-L01 | Innolux | 7.0 | 800×480 |
| LB080WV4-A1 | LG Display | 8.0 | 800×480 |
| LQ065T5AR05 | SHARP | 6.5 | 400×234 |
| LQ065T9DR52U | SHARP | 6.5 | 400×240 |
| LQ070Y5DG20 | SHARP | 7.0 | 800×480 |
| LS800JT9001 | Innolux | 8.0 | 800×600 |
