| Varenummer | LB060S01-FD01 |
| Mærke | LG Display |
| Størrelse | 6.0 |
| Ansøgning | EBK |
| Løsning | 800×600 |
| Sammensætning | EPD |
| Lysstyrke | |
| CR | |
| Farver | Grayscale |
| Baggrundsbelysning | No B/L |
| Interface | Parallel Data |
| panel mærke | LG.Philips LCD |
| panel model | LB060S01-FD01 |
| paneltype | EPD , EPD |
| panelstørrelse | 6.0 inch |
| løsning | 800×600 , SVGA |
| aktivt område | 122.4×90.6 mm |
| omrids | 137.9×104.1 mm |
| overflade | Antiglare |
| lysstyrke | |
| kontrastforhold | 8:1 (Typ.)(Reflective) |
| vise farver | Grayscale (3-bit) |
| synsvinkel | 70/70/70/70 (Max.)(CR≥6)(L/R/U/D) |
| signal interface | Parallel Data (8-bit), 39 pins |
| indgangsspænding | 3.3/22/-20V (Typ.)(VDD/VGH/VGL) |
| Ansøgning | EBK |
| A060SE02 V5 | AUO | 6.0 | 800×600 |
| BA060WV1-100 CELL | BOE | 6.0 | 480×854 |
| ED060SC1 | E Ink | 6.0 | 800×600 |
| ED060SC7 | E Ink | 6.0 | 600×800 |
| ED060SCC | E Ink | 6.0 | 600×800 |
| ED060SCM | E Ink | 6.0 | 600×800 |
| ED060XG1 | E Ink | 6.0 | 758×1024 |
| LA060N01-SD01 | LG Display | 6.0 | 720×272 |
| LB060S01-FD01 | LG Display | 6.0 | 800×600 |
| LS060S2UD01 | SHARP | 6.0 | 600×800 |
| A050VVN01.0 | AUO | 5.0 | 480×800 |
| A060SE02 V7 | AUO | 6.0 | 800×600 |
| ED060SC4 | E Ink | 6.0 | 800×600 |
| ED060SC7 | E Ink | 6.0 | 600×800 |
| ED060SCF | E Ink | 6.0 | 600×800 |
| ED060SCM | E Ink | 6.0 | 600×800 |
| ED097OC1 | E Ink | 9.7 | 1200×825 |
| LB050S01-RD01 | LG Display | 5.0 | 800×600 |
| LB071WS1-RD01 | LG Display | 7.1 | 1024×600 |
| LS060S2UD01 | SHARP | 6.0 | 600×800 |
