| Varenummer | LA060N01-SD01 |
| Mærke | LG Display |
| Størrelse | 6.0 |
| Ansøgning | CNS |
| Løsning | 720×272 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 800:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | LG Display |
| panel model | LA060N01-SD01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 6.0 inch |
| løsning | 720(RGB)×272 |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 142.56×53.856 mm |
| omrids | 164×70 mm |
| overflade | Antiglare (Haze 44%), Hard coating (3H) |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193160% |
| responstid | 15/10 (Typ.)(Tr/Td) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | Parallel RGB (1 ch, 6-bit), 40 pins |
| indgangsspænding | 5.0V (Typ.)(VCC) |
| Ansøgning | CNS |
