| Varenummer | LC215DT4A |
| Mærke | PANDA |
| Størrelse | 21.5 |
| Ansøgning | DMPC |
| Løsning | 1920×1080 |
| Sammensætning | CELL |
| Lysstyrke | 0 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | No B/L |
| Interface | LVDS |
| panel mærke | PANDA |
| panel model | LC215DT4A |
| paneltype | a-Si TFT-LCD , CELL |
| panelstørrelse | 21.5 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 476.64×268.11 mm |
| omrids | 487.54×282.91 mm |
| overflade | Antiglare, Hard coating (3H) |
| glas dybde | 0.70+0.70 mm |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC), CIE193172% |
| responstid | 5 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | DMPC |
| LC215DT4A | PANDA | 21.5 | 1920×1080 |
| LC215DTCA | PANDA | 21.5 | 1920×1080 |
| LC215EUE-SDP1 | LG Display | 21.5 | 1920×1080 |
| LC215EUE-TEA1 | LG Display | 21.5 | 1920×1080 |
| LC215EUN-SCA1 | LG Display | 21.5 | 1920×1080 |
| LC215EXE-SGA1 | LG Display | 21.5 | 1366×768 |
| LC216EXN-SDA1 | LG Display | 21.6 | 1366×768 |
| LC216EXN-SDA2 | LG Display | 21.6 | 1366×768 |
| LC216EXN-SFA1 | LG Display | 21.6 | 1366×768 |
| M215HTN01.1 | AUO | 21.5 | 1920×1080 |
| CLAA220WA01 | CPT | 21.6 | 1680×1050 |
| LM230WF5-TRA2 | LG Display | 23.0 | 1920×1080 |
| LTM201U1-L01 | Samsung | 20.1 | 1600×1200 |
| LTM220CS01 | Samsung | 22.0 | 1920×1200 |
| LTM230HL08 | Samsung | 23.0 | 1920×1080 |
| M190EN04 V5 | AUO | 19.0 | 1280×1024 |
| M230HGE-L20 | Innolux | 23.0 | 1920×1080 |
| M236H1-L01 | Innolux | 23.6 | 1920×1080 |
| NL128102BC29-01C | NLT | 19.0 | 1280×1024 |
| TM190MDS01 | Tianma | 19.0 | 1440×900 |
