| Varenummer | LD420WUB-SBG1 |
| Mærke | LG Display |
| Størrelse | 42 |
| Ansøgning | PID |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 500 |
| CR | 1000:1 |
| Farver | 16.7M/1.06B |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | LG Display |
| panel model | LD420WUB-SBG1 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 42 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | S-IPS, Normally Black, Transmissive |
| aktivt område | 930.24×523.26 mm |
| omrids | 956.4×549.4×54.5 mm, Videowall Seam 26.2 mm |
| overflade | Antiglare (Haze 10%), Hard coating (3H) |
| lysstyrke | 500 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M/1.06B (8-bit / 8-bit + Dithering) |
| responstid | 9 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | CCFLEmbedded (Inverter) |
| signal interface | LVDS (2 ch, 8/10-bit), 51 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | PID |
| LD470EUP-SEB1 | LG Display | 47 | 1920×1080 |
| LD650EUF-FHB1 | LG Display | 65 | 1920×1080 |
| LTI320AP01 | Samsung | 31.5 | 1366×768 |
| LTI460AP01-101 | Samsung | 46 | 1366×768 |
| LTI700HD01 | Samsung | 70 | 1920×1080 |
| LTI700HD01-001 | Samsung | 70 | 1920×1080 |
| P320HVN01.1 | AUO | 31.5 | 1920×1080 |
| P650HVF01.0 | AUO | 65 | 1920×1080 |
| P650HVN05.0 | AUO | 65 | 1920×1080 |
| RX372TXP01 | ROGIN | 37.2 | 1920×360 |
