| Varenummer | LTI320AP01 |
| Mærke | Samsung |
| Størrelse | 31.5 |
| Ansøgning | PID |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 450 |
| CR | 4000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | SAMSUNG |
| panel model | LTI320AP01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 31.5 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | PVA, Normally Black, Transmissive |
| aktivt område | 697.685×392.256 mm |
| omrids | 760×450 mm |
| overflade | Antiglare (Haze 7%), Hard coating (3H) |
| lysstyrke | 450 cd/m² (Typ.) |
| kontrastforhold | 4000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 20 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 4 pcsCCFLEmbedded (Inverter) |
| signal interface | LVDS (1 ch, 8-bit), 30 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | PID |
| HV320WHB-N00 | BOE | 31.5 | 1366×768 |
| LC320DXN-SFR1 | LG Display | 31.5 | 1366×768 |
| LC320WUD-SBM2 | LG Display | 31.5 | 1920×1080 |
| LTA320HA04 | Samsung | 31.5 | 1920×1080 |
| LTA320HN02-W | Samsung | 31.5 | 1920×1080 |
| LTI320AA02 | Samsung | 31.5 | 1366×768 |
| LTI320AP01 | Samsung | 31.5 | 1366×768 |
| LTI320AP02 | Samsung | 31.5 | 1366×768 |
| LTI320AP03 | Samsung | 31.5 | 1366×768 |
| V315B5-LE2 | Innolux | 31.5 | 1366×768 |
| LD320DUE-FHB1 | LG Display | 31.5 | 1920×1080 |
| LD550EUD-UFA1 | LG Display | 55 | 1920×1080 |
| LD650EUF-FHB1 | LG Display | 65 | 1920×1080 |
| LTI320AP02 | Samsung | 31.5 | 1366×768 |
| LTI460AP01-101 | Samsung | 46 | 1366×768 |
| LTI550HN07 | Samsung | 55 | 1920×1080 |
| LTI700HD01-001 | Samsung | 70 | 1920×1080 |
| LTI700HD01-006 | Samsung | 70 | 1920×1080 |
| P546HW01 V0 | AUO | 55 | 1920×1080 |
| P650HVF01.0 | AUO | 65 | 1920×1080 |
