| Varenummer | LD720DUQ-SCA1 |
| Mærke | LG Display |
| Størrelse | 72 |
| Ansøgning | PID |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 700 |
| CR | 1200:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | LG Display |
| panel model | LD720DUQ-SCA1 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 72 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | S-IPS, Normally Black, Transmissive |
| aktivt område | 1595.52×897.48 mm |
| omrids | 1666×968 mm |
| overflade | Antiglare (Haze 2%), Hard coating (3H), Reflection 2.0% (Max.) |
| lysstyrke | 700 cd/m² (Typ.) |
| kontrastforhold | 1200:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 12 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 240Hz+240Hz (60Hz Input) |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (2 ch, 10-bit), 63 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | PID |
