| Varenummer | LK645D3LZ2U |
| Mærke | SHARP |
| Størrelse | 65 |
| Ansøgning | PID |
| Løsning | 1080×1920 |
| Sammensætning | LCM |
| Lysstyrke | 450 |
| CR | 2000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | SHARP |
| panel model | LK645D3LZ2U |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 65 inch |
| løsning | 1080×1920(RGB) , FHD |
| visningstilstand | ASV, Normally Black, Transmissive |
| aktivt område | 803.52×1428.48 mm |
| omrids | 907×1555.3 mm |
| overflade | Antiglare, Hard coating (2H), Antireflection |
| lysstyrke | 450 cd/m² (Typ.) |
| kontrastforhold | 2000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 6 (Typ.)(G to G) |
| synsvinkel | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 64 pcsCCFLEmbedded (Inverter) |
| signal interface | LVDS (2 ch, 8-bit), 61 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | PID |
| LC650DUF-FGF1 | LG Display | 65 | 1920×1080 |
| LC650EQD-FGF4 | LG Display | 65 | 3840×2160 |
| LK645D3LZ2U | SHARP | 65 | 1080×1920 |
| P650HVN02.3 | AUO | 65 | 1920×1080 |
| T645HF02 V1 | AUO | 65 | 1920×1080 |
| V645HQ1-LS1 | Innolux | 65 | 1920×1080 |
| V650DJ4-KS5 | Innolux | 65 | 3840×2160 |
| V650DK1-LS1 | Innolux | 65 | 3840×2160 |
| V650HP1-LS6 | Innolux | 65 | 1920×1080 |
| V650HP1-ME2 | Innolux | 65 | 1920×1080 |
| LD420WUB-SCC1 | LG Display | 42 | 1920×1080 |
| LTI460AA01-001 | Samsung | 46 | 1366×768 |
| LTI700HD03 | Samsung | 70 | 1920×1080 |
| P320HVN01.0 | AUO | 31.5 | 1920×1080 |
| P546HW01 V0 | AUO | 55 | 1920×1080 |
| P550HVN02.2 | AUO | 55 | 1920×1080 |
| P650HVN02.2 | AUO | 65 | 1920×1080 |
| P650HVN05.0 | AUO | 65 | 1920×1080 |
| RX415TXP01 | ROGIN | 41.5 | 1920×540 |
| RX420-Z15 | ROGIN | 42 | 1920×1080 |
