| Varenummer | RX415TXP01 |
| Mærke | ROGIN |
| Størrelse | 41.5 |
| Ansøgning | PID |
| Løsning | 1920×540 |
| Sammensætning | LCM |
| Lysstyrke | 700 |
| CR | 2500:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | ROGIN |
| panel model | RX415TXP01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 41.5 inch(1/2 cut of 46") |
| løsning | 1920(RGB)×540 |
| visningstilstand | Normally Black, Transmissive |
| aktivt område | 1018.01×285.5 mm |
| omrids | 1057.5×326.5 mm |
| overflade | Antiglare (Haze 2%), Hard coating (3H) |
| lysstyrke | 700 cd/m² (Typ.) |
| kontrastforhold | 2500:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193173% |
| responstid | 6 (Typ.)(G to G) |
| synsvinkel | 88/88/88/88 (Typ.)(CR≥20)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (2 ch, 8-bit), 51 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | PID |
| RX415TXP01 | ROGIN | 41.5 | 1920×540 |
| LD320EUN-SEM1 | LG Display | 31.5 | 1920×1080 |
| LD420WUB-SBG1 | LG Display | 42 | 1920×1080 |
| LD420WUN-SCA1 | LG Display | 42 | 1920×1080 |
| LD470DUE-SFR1 | LG Display | 47 | 1920×1080 |
| LD470WUB-SCA1 | LG Display | 47 | 1920×1080 |
| LTI290LN01 | Samsung | 29.0 | 1920×540 |
| LTI370LN02 | Samsung | 37 | 1920×540 |
| LTI460AA01-001 | Samsung | 46 | 1366×768 |
| LTI550HN02 | Samsung | 55 | 1920×1080 |
| P645HW01 V0 | AUO | 65 | 1920×1080 |
