| Varenummer | LM215WF2-SLD1 |
| Mærke | LG Display |
| Størrelse | 21.5 |
| Ansøgning | DMPC |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 250 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | LG Display |
| panel model | LM215WF2-SLD1 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 21.5 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | e-IPS, Normally Black, Transmissive |
| aktivt område | 475.2×267.3 mm |
| omrids | 495.6×292.2×17 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 250 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC), CIE193171% |
| responstid | 14 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 2 pcsCCFLWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | DMPC |
| LM215WF1-TLA1 | LG Display | 21.5 | 1920×1080 |
| LM215WF1-TLB1 | LG Display | 21.5 | 1920×1080 |
| LM215WF2-SLD1 | LG Display | 21.5 | 1920×1080 |
| LM215WF3-SDA1 | LG Display | 21.5 | 1920×1080 |
| LM215WF3-SLA1 | LG Display | 21.5 | 1920×1080 |
| LM215WF3-SLC1 | LG Display | 21.5 | 1920×1080 |
| LM215WF3-SLK1 | LG Display | 21.5 | 1920×1080 |
| LM215WF3-SLN1 | LG Display | 21.5 | 1920×1080 |
| LM215WF4-TRA1 | LG Display | 21.5 | 1920×1080 |
| LM215WF5-SLA1 | LG Display | 21.5 | 1920×1080 |
| CLAA170EA10 | CPT | 17.0 | 1280×1024 |
| LTM270TT01 | Samsung | 27.0 | 2048×1152 |
| M190A1-L07 | Innolux | 19.0 | 1440×900 |
| M200O1-L05 | Innolux | 20.0 | 1600×900 |
| M215HGE-P02 | Innolux | 21.5 | 1920×1080 |
| M220Z1-L01 | Innolux | 22.0 | 1680×1050 |
| M238HVN01.0 | AUO | 23.8 | 1920×1080 |
| M240UW04 V0 | AUO | 24.0 | 1920×1200 |
| MV238FHM-N10 | BOE | 23.8 | 1920×1080 |
| NL160120BC27-14 | NLT | 21.3 | 1600×1200 |
