| Varenummer | LM215WF3-SDA1 |
| Mærke | LG Display |
| Størrelse | 21.5 |
| Ansøgning | DMPC |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 365 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| panel mærke | LG Display |
| panel model | LM215WF3-SDA1 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 21.5 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 475.2×267.3 mm |
| omrids | 495.6×305.25×16.3 mm |
| overflade | Glare (Haze 0%), Hard coating (2H), Antireflection |
| lysstyrke | 365 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 6.5/7.5 (Typ.)(Tr/Td) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 3 stringsWLEDWithout Driver |
| signal interface | eDP (4 Lanes), 30 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | DMPC |
