| Varenummer | LM215WF4-TLG1 |
| Mærke | LG Display |
| Størrelse | 21.5 |
| Ansøgning | DMPC |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 250 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | LG Display |
| panel model | LM215WF4-TLG1 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 21.5 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 476.064×267.786 mm |
| omrids | 495.6×292.2×10.7 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 250 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 1.3/3.7 (Typ.)(Tr/Td) |
| synsvinkel | 85/85/75/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 14S2PWLEDWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | DMPC |
| LM215WF1-TLA1 | LG Display | 21.5 | 1920×1080 |
| LM215WF1-TLB1 | LG Display | 21.5 | 1920×1080 |
| LM215WF1-TLE1 | LG Display | 21.5 | 1920×1080 |
| LM215WF3-SDA1 | LG Display | 21.5 | 1920×1080 |
| LM215WF3-SDC2 | LG Display | 21.5 | 1920×1080 |
| LM215WF3-SLD1 | LG Display | 21.5 | 1920×1080 |
| LM215WF3-SLK1 | LG Display | 21.5 | 1920×1080 |
| LM215WF4-TLA3 | LG Display | 21.5 | 1920×1080 |
| LM215WF4-TLG1 | LG Display | 21.5 | 1920×1080 |
| LM215WF4-TRA1 | LG Display | 21.5 | 1920×1080 |
| HT15X23-100 | HYDIS | 15.0 | 1024×768 |
| LM240WU7-SLA1 | LG Display | 24.0 | 1920×1200 |
| LM300WQ6-SLA1 | LG Display | 30.0 | 2560×1600 |
| LQ181E1DW28 | SHARP | 18.1 | 1280×1024 |
| LTM270TT01 | Samsung | 27.0 | 2048×1152 |
| M170EG01 V7 | AUO | 17.0 | 1280×1024 |
| M220EW01 V0 | AUO | 22.0 | 1680×1050 |
| M220Z1-L03 | Innolux | 22.0 | 1680×1050 |
| MT190AW02 V.W | Innolux | 19.0 | 1440×900 |
| TM190MCS02 | Tianma | 19.0 | 1440×900 |
