| Varenummer | LM240WU6-SDA1 |
| Mærke | LG Display |
| Størrelse | 24.0 |
| Ansøgning | DMPC |
| Løsning | 1920×1200 |
| Sammensætning | LCM |
| Lysstyrke | 320 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| panel mærke | LG Display |
| panel model | LM240WU6-SDA1 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 24.0 inch |
| løsning | 1920(RGB)×1200 , WUXGA |
| visningstilstand | S-IPS, Normally Black, Transmissive |
| aktivt område | 518.4×324 mm |
| omrids | 546.4×361.6×18.8 mm |
| overflade | Glare (Haze 0%), Hard coating (2H), Antireflection |
| lysstyrke | 320 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193176% |
| responstid | 6.5/7.5 (Typ.)(Tr/Td) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDWithout Driver |
| signal interface | eDP (4 Lanes), 50 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | DMPC |
