| Varenummer | LMG5278XUFC-00T |
| Mærke | KOE |
| Størrelse | 9.4 |
| Ansøgning | IA |
| Løsning | 640×480 |
| Sammensætning | LCM |
| Lysstyrke | 60 |
| CR | 18:1 |
| Farver | Monochrome |
| Baggrundsbelysning | CCFL |
| Interface | Parallel Data |
| panel mærke | HITACHI |
| panel model | LMG5278XUFC-00T |
| paneltype | FSTN-LCD , LCM |
| panelstørrelse | 9.4 inch |
| løsning | 640×480 , VGA |
| visningstilstand | STN, Black/White (Negative), Transmissive |
| aktivt område | 191.97×143.97 mm |
| omrids | 257.5×174×7 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 60 cd/m² (Typ.) |
| kontrastforhold | 18:1 (Typ.) |
| vise farver | Monochrome |
| responstid | 160/110 (Typ.)(Tr/Td) |
| synsvinkel | |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | Parallel Data (4-bit), 15 pins |
| indgangsspænding | 3.3/5.0V (Typ.)(VDD) |
| Ansøgning | IA |
| AV094Z9M-N10 | BOE | 9.4 | 1920×480 |
| LM-CA53-22NTK | SANYO | 9.4 | 640×480 |
| LM641836R | SHARP | 9.4 | 640×480 |
| LM64C15P | SHARP | 9.4 | 640×480 |
| LM64P723 | SHARP | 9.4 | 640×480 |
| LMG5278XUFC-00T | KOE | 9.4 | 640×480 |
| LMG5278XUFC-A | KOE | 9.4 | 640×480 |
| NL6448AC30-12 | NLT | 9.4 | 640×480 |
| AA150XC01 | Mitsubishi | 15.0 | 1024×768 |
| DMF-51043NFU-FW-1 | Kyocera | 9.4 | 640×480 |
| G070VTT01.0 | AUO | 7.0 | 800×480 |
| G104V1-T03 | Innolux | 10.4 | 640×480 |
| KCS072VG1MJ-G40 | Kyocera | 7.2 | 640×480 |
| LQ104V1LG61 | SHARP | 10.4 | 640×480 |
| LQ64D34 | SHARP | 6.4 | 640×480 |
| LTM10C209A | TOSHIBA | 10.4 | 640×480 |
| NL10276BC16-06D | NLT | 8.4 | 1024×768 |
| TX18D40VM1CAA | KOE | 7.0 | 800×480 |
