| Varenummer | AV094Z9M-N10 |
| Mærke | BOE |
| Størrelse | 9.4 |
| Ansøgning | CNS |
| Løsning | 1920×480 |
| Sammensætning | LCM |
| Lysstyrke | 500 |
| CR | 950:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | BOE |
| panel model | AV094Z9M-N10 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 9.4 inch |
| løsning | 1920(RGB)×480 |
| visningstilstand | ADS, Normally Black, Transmissive |
| aktivt område | 230.4×57.6 mm |
| omrids | 243.86×73.7×11.38 mm |
| overflade | Clear |
| lysstyrke | 500 cd/m² (Min.) |
| kontrastforhold | 950:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193170% |
| responstid | 30 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 8-bit), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | CNS |
