| Varenummer | LP101WH4-SLAA |
| Mærke | LG Display |
| Størrelse | 10.1 |
| Ansøgning | PAD |
| Løsning | 1366×768 |
| Sammensætning | Assembly |
| Lysstyrke | 315 |
| CR | 800:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | LG Display |
| panel model | LP101WH4-SLAA |
| paneltype | a-Si TFT-LCD , Assembly |
| panelstørrelse | 10.1 inch |
| løsning | 1366(RGB)×768 , WXGA |
| aktivt område | 222.52×125.11 mm |
| omrids | 254.3×158×5.45 mm |
| overflade | Anti Fingerprint, Hard coating (8H) |
| lysstyrke | 315 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| signal interface | LVDS (1 ch, 8-bit), 39 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | PAD |
| LP101WH1-TLA3 | LG Display | 10.1 | 1366×768 |
| LP101WH1-TLB5 | LG Display | 10.1 | 1366×768 |
| LP101WH4-SLA3 | LG Display | 10.1 | 1366×768 |
| LP101WH4-SLA6 | LG Display | 10.1 | 1366×768 |
| LP101WS1-TLA1 | LG Display | 10.1 | 1024×576 |
| LP101WS1-TLB1 | LG Display | 10.1 | 1024×576 |
| LP101WS1-TLB2 | LG Display | 10.1 | 1024×576 |
| LP101WS1-TLB3 | LG Display | 10.1 | 1024×576 |
| LP101WX1-SLN2 | LG Display | 10.1 | 1280×800 |
| LP101WX2-SLA1 | LG Display | 10.1 | 1280×800 |
| BP101WX1-206 | BOE | 10.1 | 1280×800 |
| HT12X21-221 | HYDIS | 12.1 | 1024×768 |
| LD070WU1-SM01 | LG Display | 7.0 | 1200×1920 |
| LD089WU1-SM01 | LG Display | 8.9 | 1920×1200 |
| LD101WX2-SLP1 | LG Display | 10.1 | 1280×800 |
| LP101WH4-SLAF | LG Display | 10.1 | 1366×768 |
| LPM070W425D | JDI | 7.0 | 1200×1920 |
| LQ097L1JY01A | SHARP | 9.7 | 2048×1536 |
| LTL101AL06-801 | Samsung | 10.1 | 1280×800 |
| Q070LRE-LA1 | Innolux | 7.0 | 1024×600 |
