| Varenummer | LPM070W425D |
| Mærke | JDI |
| Størrelse | 7.0 |
| Ansøgning | PAD |
| Løsning | 1200×1920 |
| Sammensætning | CELL |
| Lysstyrke | 0 |
| CR | 1100:1 |
| Farver | 16.7M |
| Baggrundsbelysning | No B/L |
| Interface | MIPI |
| panel mærke | JDI |
| panel model | LPM070W425D |
| paneltype | LTPS TFT-LCD , CELL |
| panelstørrelse | 7.0 inch |
| løsning | 1200(RGB)×1920 , WUXGA |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 94.5×151.2 mm |
| omrids | 97.3×159.4 mm |
| overflade | |
| glas dybde | 0.25+0.25 mm |
| transmissivitet | 5.2% (Typ.)(with Polarizer) |
| kontrastforhold | 1100:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| driver ic | Built-in ISL97692IRTZ |
| signal interface | MIPI (4 data lanes), 31 pins |
| indgangsspænding | 1.8/3.0/3.0V (Typ.)(IOVCC/VDD/VDDP) |
| Ansøgning | PAD |
