| Varenummer | LP116WH6-SPA2 |
| Mærke | LG Display |
| Størrelse | 11.6 |
| Ansøgning | NBPC |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 800:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| panel mærke | LG Display |
| panel model | LP116WH6-SPA2 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 11.6 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 256.125×144 mm |
| omrids | 268.9×158×3.2 mm |
| form stil | Slim (PCBA Flat, Depth ≤3.2mm) |
| overflade | Antiglare (Haze 25%), Hard coating |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193160% |
| responstid | 20 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | eDP (1 Lane), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| LP116WF1-SPA1 | LG Display | 11.6 | 1920×1080 |
| LP116WH1-TLA1 | LG Display | 11.6 | 1366×768 |
| LP116WH1-TLN1 | LG Display | 11.6 | 1366×768 |
| LP116WH1-TLP1 | LG Display | 11.6 | 1366×768 |
| LP116WH4-SLA1 | LG Display | 11.6 | 1366×768 |
| LP116WH4-SLN1 | LG Display | 11.6 | 1366×768 |
| LP116WH4-SLN2 | LG Display | 11.6 | 1366×768 |
| LP116WH4-TJA3 | LG Display | 11.6 | 1366×768 |
| LP116WH6-SLA1 | LG Display | 11.6 | 1366×768 |
| LP116WH6-SPA2 | LG Display | 11.6 | 1366×768 |
| B101EW02 V0 | AUO | 10.1 | 1280×720 |
| HB140WX1-500 | BOE | 14.0 | 1366×768 |
| LP140WH1-TLA3 | LG Display | 14.0 | 1366×768 |
| LP154WP4-TLA1 | LG Display | 15.4 | 1440×900 |
| LP156WH8-TLA2 | LG Display | 15.6 | 1366×768 |
| LP171WP4-TLB4 | LG Display | 17.1 | 1440×900 |
| LP171WU6-TLA2 | LG Display | 17.1 | 1920×1200 |
| LTN173KT01-W01 | Samsung | 17.3 | 1600×900 |
| LTN173KT01-W04 | Samsung | 17.3 | 1600×900 |
| N173FGE-L21 | Innolux | 17.3 | 1600×900 |
