| Varenummer | LP133WH1-TLA1 |
| Mærke | LG Display |
| Størrelse | 13.3 |
| Ansøgning | NBPC |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 200 |
| CR | 300:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | LG Display |
| panel model | LP133WH1-TLA1 1 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 13.3 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 293.42×164.97 mm |
| omrids | 307.6×183.1×5.5 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| overflade | Glare (Haze 0%), Hard coating (3H) |
| lysstyrke | 200 cd/m² (Typ.) |
| kontrastforhold | 300:1 (Min.) |
| vise farver | 262K (6-bit), CIE193145% |
| responstid | 16 (Typ.)(Tr+Td) |
| synsvinkel | 40/40/10/30 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 6-bit), 40 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| LP133WF1-SPA1 | LG Display | 13.3 | 1920×1080 |
| LP133WF2-SPA1 | LG Display | 13.3 | 1920×1080 |
| LP133WH2-SPA2 | LG Display | 13.3 | 1366×768 |
| LP133WH2-TLA3 | LG Display | 13.3 | 1366×768 |
| LP133WH2-TLB2 | LG Display | 13.3 | 1366×768 |
| LP133WH2-TLL1 | LG Display | 13.3 | 1366×768 |
| LP133WH2-TLL3 | LG Display | 13.3 | 1366×768 |
| LP133WH2-TLL4 | LG Display | 13.3 | 1366×768 |
| LP133WX1-TLB1 | LG Display | 13.3 | 1280×800 |
| LP133WX3-TLA6 | LG Display | 13.3 | 1280×800 |
| B140HAN01.0 | AUO | 14.0 | 1920×1080 |
| B141EW05 V4 | AUO | 14.1 | 1280×800 |
| LP101WH1-TLA2 | LG Display | 10.1 | 1366×768 |
| LP156WF4-SLC1 | LG Display | 15.6 | 1920×1080 |
| LP171WU5-TLA1 | LG Display | 17.1 | 1920×1200 |
| LTN154X5-L02 | Samsung | 15.4 | 1280×800 |
| LTN173HT02-C01 | Samsung | 17.3 | 1920×1080 |
| M116NWR1 R3 | IVO | 11.6 | 1366×768 |
| N141I6-D11 | Innolux | 14.1 | 1280×800 |
| QD14FL02 Rev.01 | QDI | 14.1 | 1400×1050 |
