| Varenummer | LTN154X5-L02 |
| Mærke | Samsung |
| Størrelse | 15.4 |
| Ansøgning | NBPC |
| Løsning | 1280×800 |
| Sammensætning | LCM |
| Lysstyrke | 490 |
| CR | 700:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | SAMSUNG |
| panel model | LTN154X5-L02 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 15.4 inch |
| løsning | 1280(RGB)×800 , WXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 331.2×207 mm |
| omrids | 344×224×10.5 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| overflade | Glare (Haze 0%), Hard coating (3H) |
| lysstyrke | 490 cd/m² (Typ.) |
| kontrastforhold | 700:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193172% |
| responstid | 16 (Typ.)(Tr+Td) |
| synsvinkel | 65/65/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 2 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 6-bit), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| rohs: | |
| Ansøgning | NBPC |
| LTN154AT07-L01 | Samsung | 15.4 | 1280×800 |
| LTN154AT09-102 | Samsung | 15.4 | 1280×800 |
| LTN154CT04-D01 | Samsung | 15.4 | 1920×1200 |
| LTN154P1-L01 | Samsung | 15.4 | 1680×1050 |
| LTN154U1-L03 | Samsung | 15.4 | 1920×1200 |
| LTN154X2-L02 | Samsung | 15.4 | 1280×800 |
| LTN154X3-L03 | Samsung | 15.4 | 1280×800 |
| LTN154X3-L04 | Samsung | 15.4 | 1280×800 |
| LTN154X3-L09-0 | Samsung | 15.4 | 1280×800 |
| LTN154X3-L09-G | Samsung | 15.4 | 1280×800 |
| B140HAN01.2 | AUO | 14.0 | 1920×1080 |
| B141XG13 V8 | AUO | 14.1 | 1024×768 |
| B170PW06 V2 | AUO | 17.0 | 1440×900 |
| LP140WH1-TLE3 | LG Display | 14.0 | 1366×768 |
| LP140WX1-TL01 | LG Display | 14.0 | 1280×768 |
| LTD106EXXF | TOSHIBA | 10.6 | 1280×768 |
| LTD133EV2F | TOSHIBA | 13.3 | 1280×800 |
| LTN154AT07-L01 | Samsung | 15.4 | 1280×800 |
| M133NWN1 R3 | IVO | 13.3 | 1366×768 |
| N133BGE-EB1 | Innolux | 13.3 | 1366×768 |
