| Varenummer | QD14FL02 Rev.01 |
| Mærke | QDI |
| Størrelse | 14.1 |
| Ansøgning | NBPC |
| Løsning | 1400×1050 |
| Sammensætning | LCM |
| Lysstyrke | 175 |
| CR | 300:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | QDI |
| panel model | QD14FL02 Rev.01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 14.1 inch |
| løsning | 1400(RGB)×1050 , SXGA+ |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 285.7×214.3 mm |
| omrids | 299×240.6×5.5 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 175 cd/m² (Typ.) |
| kontrastforhold | 300:1 (Min.) |
| vise farver | 262K (6-bit), CIE193150% |
| responstid | 10/15 (Typ.)(Tr/Td) |
| synsvinkel | 40/40/10/30 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1 pcsCCFLEmbedded (Inverter) |
| signal interface | LVDS (2 ch, 6-bit), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| rohs: | |
