| Varenummer | LP133WP1-TJAA |
| Mærke | LG Display |
| Størrelse | 13.3 |
| Ansøgning | NBPC |
| Løsning | 1440×900 |
| Sammensætning | CELL |
| Lysstyrke | 0 |
| CR | 600:1 |
| Farver | 262K |
| Baggrundsbelysning | No B/L |
| Interface | eDP |
| panel mærke | LG Display |
| panel model | LP133WP1-TJAA |
| paneltype | a-Si TFT-LCD , CELL |
| panelstørrelse | 13.3 inch |
| løsning | 1440(RGB)×900 , WXGA+ |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 286.2×178.875 mm |
| omrids | 299.41×190.78×0 mm |
| overflade | Glare (Haze 0%), Hard coating (3H) |
| transmissivitet | 5.5% (Typ.)(with Polarizer) |
| kontrastforhold | 600:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 16 (Typ.)(Tr+Td) |
| synsvinkel | 70/70/50/50 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| signal interface | eDP (1 Lane), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
