| Varenummer | LP133WX2-TLC1 |
| Mærke | LG Display |
| Størrelse | 13.3 |
| Ansøgning | NBPC |
| Løsning | 1280×800 |
| Sammensætning | LCM |
| Lysstyrke | 275 |
| CR | 600:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | LG.Philips LCD |
| panel model | LP133WX2-TLC1 6 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 13.3 inch |
| løsning | 1280(RGB)×800 , WXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 286.08×178.8 mm |
| omrids | 307.38×203.1×3.6 mm |
| form stil | Flat (PCBA Flat, Depth 3.4~4.0mm) |
| overflade | Glare (Haze 0%), Hard coating (2H), Antireflection |
| lysstyrke | 275 cd/m² (Typ.) |
| kontrastforhold | 600:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193145% |
| responstid | 16 (Typ.)(Tr+Td) |
| synsvinkel | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 9S6PWLEDWithout Driver |
| signal interface | LVDS (1 ch, 6-bit), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| LP133WH1-TLB1 | LG Display | 13.3 | 1366×768 |
| LP133WH2-SPA1 | LG Display | 13.3 | 1366×768 |
| LP133WH2-TLL2 | LG Display | 13.3 | 1366×768 |
| LP133WX1-TLB1 | LG Display | 13.3 | 1280×800 |
| LP133WX1-TLC1 | LG Display | 13.3 | 1280×800 |
| LP133WX2-TLA1 | LG Display | 13.3 | 1280×800 |
| LP133WX2-TLA2 | LG Display | 13.3 | 1280×800 |
| LP133WX2-TLG6 | LG Display | 13.3 | 1280×800 |
| LP133WX3-TLA2 | LG Display | 13.3 | 1280×800 |
| LP133WX3-TLA4 | LG Display | 13.3 | 1280×800 |
| B133XW03 V2 | AUO | 13.3 | 1366×768 |
| B140QAN01.1 | AUO | 14.0 | 2560×1440 |
| B156XW04 V5 | AUO | 15.6 | 1366×768 |
| CLAA154WB09A | CPT | 15.4 | 1280×800 |
| LP140WH1-TLA2 | LG Display | 14.0 | 1366×768 |
| LP154WX4-TLC5 | LG Display | 15.4 | 1280×800 |
| LP156WD1-TPB1 | LG Display | 15.6 | 1600×900 |
| LP171WP4-TLQ1 | LG Display | 17.1 | 1440×900 |
| LTN154X9-L02 | Samsung | 15.4 | 1280×800 |
| N141X6-L01 | Innolux | 14.1 | 1024×768 |
