| Varenummer | LP154W02-B1K6 |
| Mærke | LG Display |
| Størrelse | 15.4 |
| Ansøgning | NBPC |
| Løsning | 1680×1050 |
| Sammensætning | LCM |
| Lysstyrke | 185 |
| CR | 300:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | LG.Philips LCD |
| panel model | LP154W02-B1K6 6 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 15.4 inch |
| løsning | 1680(RGB)×1050 , WSXGA+ |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 331.38×207.11 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| overflade | Antiglare (Haze 12%) |
| lysstyrke | 185 cd/m² (Typ.) |
| kontrastforhold | 300:1 (Min.) |
| vise farver | 262K (6-bit), CIE193145% |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 65/65/50/50 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | LVDS (2 ch, 6-bit), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| LP154W01-TLE5 | LG Display | 15.4 | 1280×800 |
| LP154W02-B1K2 | LG Display | 15.4 | 1680×1050 |
| LP154W02-TL06 | LG Display | 15.4 | 1680×1050 |
| LP154W02-TL10 | LG Display | 15.4 | 1680×1050 |
| LP154WE3-TLA1 | LG Display | 15.4 | 1680×1050 |
| LP154WP3-TLA2 | LG Display | 15.4 | 1440×900 |
| LP154WX4-TLB2 | LG Display | 15.4 | 1280×800 |
| LP154WX5-TLA1 | LG Display | 15.4 | 1280×800 |
| LP154WX5-TLB2 | LG Display | 15.4 | 1280×800 |
| LP154WX7-TLA1 | LG Display | 15.4 | 1280×800 |
| B133EW07 V2 | AUO | 13.3 | 1280×800 |
| B154EW01 V8 | AUO | 15.4 | 1280×800 |
| B173RW01 V1 | AUO | 17.3 | 1600×900 |
| LP150X09-B2K3 | LG Display | 15.0 | 1024×768 |
| LP156WH1-TLA3 | LG Display | 15.6 | 1366×768 |
| LTN154AT09-102 | Samsung | 15.4 | 1280×800 |
| LTN156KT06-801 | Samsung | 15.6 | 1600×900 |
| N116HSE-EBC | Innolux | 11.6 | 1920×1080 |
| N154Z1-L02 | Innolux | 15.4 | 1680×1050 |
| N156BGE-L41 | Innolux | 15.6 | 1366×768 |
