| Varenummer | LP171WP4-TLN2 |
| Mærke | LG Display |
| Størrelse | 17.1 |
| Ansøgning | NBPC |
| Løsning | 1440×900 |
| Sammensætning | LCM |
| Lysstyrke | 200 |
| CR | 500:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | LG Display |
| panel model | LP171WP4-TLN2 9 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 17.1 inch |
| løsning | 1440(RGB)×900 , WXGA+ |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 367.2×229.5 mm |
| omrids | 382.2×244.5×6.5 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| overflade | Glare (Haze 0%), Hard coating (2H) |
| lysstyrke | 200 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193145% |
| responstid | 16 (Typ.)(Tr+Td) |
| synsvinkel | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | LVDS (2 ch, 6-bit), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| LP171WE2-TLA2 | LG Display | 17.1 | 1680×1050 |
| LP171WE3-TLA5 | LG Display | 17.1 | 1680×1050 |
| LP171WP4-TLN2 | LG Display | 17.1 | 1440×900 |
| LP171WP4-TLQ1 | LG Display | 17.1 | 1440×900 |
| LP171WP9-TLB2 | LG Display | 17.1 | 1440×900 |
| LP171WU1-A4K2 | LG Display | 17.1 | 1920×1200 |
| LP171WU1-A4K3 | LG Display | 17.1 | 1920×1200 |
| LP171WU5-TLA1 | LG Display | 17.1 | 1920×1200 |
| LP171WU5-TLA2 | LG Display | 17.1 | 1920×1200 |
| LP171WX2-TLB2 | LG Display | 17.1 | 1440×900 |
| B140HAT02.0 | AUO | 14.0 | 1920×1080 |
| HV150UX1-100 | HYDIS | 15.0 | 1600×1200 |
| LP140WH1-TLD1 | LG Display | 14.0 | 1366×768 |
| LP140WH2-TLE2 | LG Display | 14.0 | 1366×768 |
| LP141WX3-TLN4 | LG Display | 14.1 | 1280×800 |
| LTN140AT07-T01 | Samsung | 14.0 | 1366×768 |
| LTN154P1-L03 | Samsung | 15.4 | 1680×1050 |
| M116NWR1 R0 | IVO | 11.6 | 1366×768 |
| N134B6-L01 | Innolux | 13.4 | 1366×768 |
| N140BGE-E33 | Innolux | 14.0 | 1366×768 |
