| Varenummer | LQ025A3DD01 |
| Mærke | SHARP |
| Størrelse | 2.5 |
| Ansøgning | DSC |
| Løsning | 480×240 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 400:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | Serial RGB |
| panel mærke | SHARP |
| panel model | LQ025A3DD01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 2.5 inch |
| løsning | 480×240 |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 49.89×37.44 mm |
| omrids | 58.85×43.55 mm |
| overflade | Clear, Hard coating (2H) |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC), CIE193135% |
| responstid | 30/50 (Typ.)(Tr/Td) |
| synsvinkel | 50/50/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 3S1PWLEDWithout Driver |
| signal interface | Serial RGB (8-bit) + SPI, 39 pins |
| Ansøgning | DSC |
