| Varenummer | LQ065T9DR52U |
| Mærke | SHARP |
| Størrelse | 6.5 |
| Ansøgning | CNS |
| Løsning | 400×240 |
| Sammensætning | LCM |
| Lysstyrke | 220 |
| CR | 60:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | TTL |
| panel mærke | SHARP |
| panel model | LQ065T9DR52U |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 6.5 inch |
| løsning | 400(RGB)×240 , WQVGA |
| visningstilstand | TN, Normally White, Transflective |
| aktivt område | 143.4×79.326 mm |
| omrids | 155×89.2 mm |
| overflade | Antiglare, Antireflection |
| lysstyrke | 220 cd/m² (Typ.) |
| kontrastforhold | 60:1 (Min.)(Transmissive)5:1 (Typ.)(Reflective) |
| vise farver | 262K (6-bit) |
| responstid | 10/25 (Typ.)(Tr/Td) |
| synsvinkel | 50/50/40/45 (Typ.)(CR≥5)(L/R/U/D) |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit), 31 pins |
| indgangsspænding | 5/10/-10V (Typ.)(VSH/VGH/VGL) |
| Ansøgning | CNS |
