| Varenummer | LQ125T1JX03C |
| Mærke | Sharp |
| Størrelse | 12.5 |
| Ansøgning | Laptop Pad & Tab |
| Løsning | 2560×1440 |
| Sammensætning | Oxide TFT-LCD, LCM |
| Lysstyrke | |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| panel mærke | Sharp |
| panel model | LQ125T1JX03C (SHP142C) |
| panelstørrelse | 12.5" |
| paneltype | Oxide TFT-LCD, LCM |
| løsning | 2560(RGB)×1440, Quad-HD, 235PPI |
| pixel format | RGB Vertical Stripe |
| udstillingsområde | 276.48(W)×155.52(H) mm |
| bezel åbning | - |
| konturstørrelse | 282.68(W)×169.93(H) ×4.9(D) mm |
| overflade | Glare (Haze 0%), Hard coating |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) (TM) |
| synsvinkel | 80/80/80/80 (Min.)(CR≥10) |
| visningstilstand | IPS, Normally Black, Transmissive |
| bedste udsigt på | Symmetry |
| responstid | 25 (Typ.)(Tr+Td) |
| vise farver | 16.7M |
| lampe type | WLED , 15K hours , With LED Driver |
| frekvens | 60Hz |
| berøringsskærm | Without |
| form stil | Slim (PCBA Bent, T≤3.0mm) |
| Ansøgning | Laptop Pad & Tablet |
| signal interface | eDP (4 Lanes) , eDP1.3 , HBR1 (2.7G/lane) , 40 pins Connector |
| indgangsspænding | 3.3V (Typ.) |
| miljø | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
