| Varenummer | LQ133M1JW31 |
| Mærke | Sharp |
| Størrelse | 13.3 |
| Ansøgning | Laptop |
| Løsning | 1920×1080 |
| Sammensætning | Oxide TFT-LCD, LCM |
| Lysstyrke | |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| mærke | Sharp |
| model | LQ133M1JW31 |
| diagonal størrelse | 13.3 inch |
| type | Oxide TFT-LCD, LCM |
| pixel format | 1920(RGB)×1080 [FHD] 166PPI |
| konfiguration | RGB Vertical Stripe |
| aktivt område | 293.76(H)×165.24(V) mm |
| omrids dim. | 299.46(H)×185.4(V) ×2.57(D) mm |
| bezel område | - |
| behandling | Hard coating (3H) |
| luminans | 300 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) (TM) |
| visningsretning | Symmetry |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10) |
| driftstilstand | IPS, Normally Black, Transmissive |
| støtte farve | 16.7M |
| lyskilde | WLED , 15K hours , With LED Driver |
| form stil | Slim (PCBA Flat, T≤3.2mm) |
| designet til | Laptop |
| billedhastighed | 60Hz |
| berøringspanel | Without |
| interface type | eDP (2 Lanes) , eDP1.3 , HBR1 (2.7G/lane) , 30 pins Connector |
| Strømforsyning | 3.3V (Typ.) |
| miljø | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| LP133X3-A | LG Display | 13.3 | 1024×768 |
| LQ133K1LA04 | SHARP | 13.3 | 1280×800 |
| LQ133K1LA4A | SHARP | 13.3 | 1280×800 |
| LQ133K1LD4B | SHARP | 13.3 | 1280×800 |
| LQ133M1JW03 | SHARP | 13.3 | 1920×1080 |
| LQ133T1JW01 | SHARP | 13.3 | 2560×1440 |
| LQ133T1JW02 | SHARP | 13.3 | 2560×1440 |
| LQ133T1JW19 | SHARP | 13.3 | 2560×1440 |
| LTN133HL01-301 | Samsung | 13.3 | 1920×1080 |
| N133BGE-L21 | Innolux | 13.3 | 1366×768 |
