| Varenummer | LQ133T1JW23 |
| Mærke | Sharp |
| Størrelse | 13.3 |
| Ansøgning | Laptop |
| Løsning | 2560×1440 |
| Sammensætning | Oxide TFT-LCD, LCM |
| Lysstyrke | |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| mærke | Sharp |
| model | LQ133T1JW23 (SHP1412) |
| diagonal størrelse | 13.3 inch |
| type | Oxide TFT-LCD, LCM |
| pixel format | 2560(RGB)×1440 [Quad-HD] 221PPI |
| konfiguration | RGB Vertical Stripe |
| aktivt område | 293.76(H)×165.24(V) mm |
| omrids dim. | 304.98(H)×187.9(V) ×2.6(D) mm |
| bezel område | - |
| behandling | Antiglare (Haze 42%) |
| luminans | 350 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) (TM) |
| visningsretning | Symmetry |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10) |
| driftstilstand | VA, Normally Black, Transmissive |
| støtte farve | 16.7M 100% sRGB |
| lyskilde | WLED , 10K hours , With LED Driver |
| form stil | Slim (PCBA Flat, T≤3.2mm) |
| designet til | Laptop |
| billedhastighed | 60Hz |
| berøringspanel | Without |
| interface type | eDP (4 Lanes) , eDP1.3 , HBR1 (2.7G/lane) , 40 pins Connector |
| Strømforsyning | 3.3V (Typ.) |
| miljø | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
