| Varenummer | LQ150X1DWF1 |
| Mærke | SHARP |
| Størrelse | 15.0 |
| Ansøgning | DMPC |
| Løsning | 1024×768 |
| Sammensætning | LCM |
| Lysstyrke | 250 |
| CR | 400:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | TTL |
| panel mærke | SHARP |
| panel model | LQ150X1DWF1 1 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 15.0 inch |
| løsning | 1024(RGB)×768 , XGA |
| visningstilstand | MVA, Normally Black, Transmissive |
| aktivt område | 304.128×228.096 mm |
| omrids | 347.3×263.5×16.8 mm |
| overflade | Antiglare (Haze 25%), Hard coating (2H) |
| lysstyrke | 250 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 15/10 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 4 pcsCCFLWithout Driver |
| signal interface | CMOS/TTL (2 ch, 6-bit), 60 pins |
| indgangsspænding | 5.0V (Typ.)(VCC) |
| Ansøgning | DMPC |
| LQ150X1DWF1 | SHARP | 15.0 | 1024×768 |
| LQ150X1LAM3 | SHARP | 15.0 | 1024×768 |
| LQ150X1LBE1 | SHARP | 15.0 | 1024×768 |
| LQ150X1LG55 | SHARP | 15.0 | 1024×768 |
| LQ150X1LG81 | SHARP | 15.0 | 1024×768 |
| LQ150X1LG92 | SHARP | 15.0 | 1024×768 |
| LQ150X1LGB1 | SHARP | 15.0 | 1024×768 |
| LQ150X1LGN1 | SHARP | 15.0 | 1024×768 |
| LQ150X1LW94 | SHARP | 15.0 | 1024×768 |
| LQ150X1LW96 | SHARP | 15.0 | 1024×768 |
| HR236WU1-100 | BOE | 23.6 | 1920×1080 |
| LM190E03-TLB4 | LG Display | 19.0 | 1280×1024 |
| LM190E09-TLB1 | LG Display | 19.0 | 1280×1024 |
| LM195WD1-TLA1 | LG Display | 19.5 | 1600×900 |
| LM240WU6-SDA1 | LG Display | 24.0 | 1920×1200 |
| M215HW01 V5 | AUO | 21.5 | 1920×1080 |
| M270HHF-L10 | Innolux | 27.0 | 1920×1080 |
| M270HVN02.1 | AUO | 27.0 | 1920×1080 |
| MT220WW01 V.5 | Innolux | 22.0 | 1680×1050 |
| NL128102AC23-01 | NLT | 15.4 | 1280×1024 |
